High-Speed Forging Machine For Alloy Industries
High-Speed Forging Machine For Alloy Industries, maintain a rapid steep per minute at 20-40 pieces balls per minute & cover the ball size:100-150MM, Ball surface hardness:56-62HRC, Ball core hardness: 54-59HRC, Impact toughness: ＞20 J/CM2, Suitable for steel ball projects with an annual output of 100000 tons for different Mine Industry.
Introduction
High-Speed Forging Machine For Alloy Industries, maintain a rapid steep per minute at 20-40 pieces balls per minute, Suitable for steel ball projects with an annual output of 100000 tons.
Specifications
D100MM-150MM High-Speed Forging Machine For Alloy Industries
High speed：20-40 balls per minute
BALL SURFACE HARDNESS: 56-62HRC
BALL CORE HARDNESS: 54-59HRC
IMPACT TOUGHNESS: ＞20 J/CM2
Product Detail
| Product name | High-Speed Forging Machine For Alloy Industries |
| Application | Grinding ball for Mineral processing SAG ball mill & section 1 ball mill |
| Original | Jiangyin, China |
| Certification | ISO9001, ISO14001, OHSAS18001 etc. |
| Price | Negotiable |
| Material | Q235, 45# |
| Voltage | 380V 50Hz, or the voltage can be as local demand |
| Payment term | TT, LC |
| Delivery date | Negotiable |
| Packing | export standard |
| Market | Middle East/ Africa/Asia/South America/Europe/North America |
| Warranty | 1 year |
| MOQ | 1 set |
| Delivery time | 6-8 months per set |
Features
D100MM-150MM High-Speed Forging Machine For Alloy Industries:
- Equipment Frame: Welding
- Spindle Forging Capacity: 800 Tons
- Shear Ability: 350 Tons
- Total Travel Of Spindle: 286mm
- Total Travel Of Shear: 240mm
- Feeding: Spindle Linkage Feeding
- Steel Rod Feeding Temperature: 1100℃
- Motor: Inventor Motor-132kw
- Electric Supply: 380v
- Control: Inverter, Touch Screen, Stepless Speed Regulation
The quick forging machine is to meet the demand, the frame adopts closed integral steel plate welding, which not only has good precision, regidity and strength performance, but also has the characteristics of simple installation and convenient operation. This series of fast forging machine have the characteristics of high precision, high strength and high rigidity, and are suitable for forging ball, ring and cake-shape parts.
The equipment is mainly composed of the fuselage, transmission, cluth, brake, slider, feeding mechanism, material breaking mechanism, transfer mechanism, upper ejection mechanism, lower ejection mechanism, cam controller, lubrication system, protective cover, pneumatic system and elecrical system and other components.
Production Steps
- Steel rod inspection
- Steel rod heating
- Quick Forging Machines
- Ball rounder machine
- Strong cooling
- Ring furnace (Ball Reheating Furnace)
- Quenching
- Tempering
Why choose us ?
1. We are the biggest factory of grinding ball production lines in jiangsu province ,china .
2. Quality Control through the whole Manufacturing process.
3. General Inspection on fixing before Packing.
4. Our hardware all passed ISO 9001.
5. After you make order, we will Follow up the whole process and Update it to you. Collecting goods, Loading containers and Tracking goods transport information for you.
